Keyence Light CURTAIN TRANSMITTER GL-R24H-T

The Keyence Light CURTAIN TRANSMITTER GL-R24H-T is a high-performance industrial sensor designed for precise and reliable detection in automated environments. This transmitter is part of the renowned Keyence product line, known for its durability and advanced technology.

Product Features:

• Compact Design: The GL-R24H-T features a sleek, yellow and black design with a diameter of 25mm (0.98 inches), making it easy to integrate into existing systems without requiring significant space.
• High Detection Height: With a protection height of up to 460mm (505mm), this transmitter ensures comprehensive coverage for various applications, including safety barriers and object detection.
• Fast Response Time: The transmitter offers a rapid response time of 7ms (Channel 0) and 9.5ms (Channel A or B), enabling real-time monitoring and quick decision-making in fast-paced industrial settings.
• Wide Operating Distance: The GL-R24H-T supports an operating distance ranging from 0.2m to 15m, providing flexibility for diverse application scenarios.
• Robust Construction: Built to withstand harsh industrial conditions, this transmitter is designed for long-term reliability and minimal maintenance.
• PNP/NPN Output: Compatible with both PNP and NPN output configurations, the GL-R24H-T ensures seamless integration with a wide range of control systems.

Specifications:

• Rated Voltage/Current: 24V DC, 57mA Class 2
• Type of Power Supply: See the instruction manual for detailed power supply information.
• Response Time: 7ms (Channel 0) / 9.5ms (Channel A or B)
• Detection Height (Protection Height): 460mm (505mm)
• Detection Capability: Ø25mm (default setting)
• OSSD Rating: PNP/NPN max 500mA
• Operating Distance: 0.2m - 15m
• EAA Light Emission Angle: ±2.5° (3m or more)

Applications:

The Keyence Light CURTAIN TRANSMITTER GL-R24H-T is ideal for use in a variety of industrial applications, including:

• Safety Barriers: Protecting workers by detecting unauthorized access to hazardous areas.
• Object Detection: Identifying and counting objects on conveyor belts or in storage areas.
• Automation Systems: Enhancing the efficiency and accuracy of automated production lines.
• Quality Control: Ensuring consistent product quality by monitoring manufacturing processes.

Benefits:

• Enhanced Safety: Provides reliable detection to prevent accidents and ensure workplace safety.
• Improved Efficiency: Fast response times and accurate detection capabilities optimize production processes.
• Cost-Effective: Long-lasting design reduces the need for frequent replacements, saving on maintenance costs.
• Easy Integration: Compatible with various control systems, making installation straightforward and hassle-free.
