Product Description
The Siemens 60A Circuit Breaker, model 3RV1742-5LD10, is a high-performance electrical protection device designed for commercial and industrial applications. This robust circuit breaker offers reliable overload and short-circuit protection, ensuring the safety and longevity of your electrical systems.
Product Features:
- Rated Current: 60A
- Maximum Voltage: 600V AC
- Frequency Range: 50/60Hz
- Interrupting Capacity: 20kA at 600V AC, 65kA at 480V AC
- Three-pole configuration for versatile use in three-phase systems
- Durable white and black housing for enhanced visibility and durability
- Clear ON/OFF indicator and TEST button for easy operation and maintenance
- Compact design for easy installation in control panels and switchboards
- Complies with UL489 standards for safety and performance
Specifications:
- Part Number: 3RV1742-5LD10
- Series: Sirius S3
- Enclosure Type: Non-enclosed
- Mounting Type: DIN rail or panel mount
- Operating Temperature Range: -25°C to +60°C
- Weight: Approximately 1.5 kg
Applications:
- Industrial machinery and equipment
- Commercial building electrical systems
- Power distribution panels
- Renewable energy systems (solar, wind)
- Manufacturing plants and process control systems
Benefits:
- Enhanced safety through precise current monitoring and rapid tripping
- Improved system reliability with proven Siemens quality and engineering
- Cost-effective solution for protecting valuable electrical assets
- Easy integration into existing electrical infrastructure
- Long service life with minimal maintenance requirements
