ALLEN BRADLEY 1 POLE 15A CIRCUIT BREAKER 1489 C15 A 1498-M1C150R

Allen-Bradley 1 Pole 15A Circuit Breaker (Model 1489-M1C150R) is a robust and reliable electrical protection device designed for commercial and industrial applications. This compact circuit breaker offers precise current limiting and overload protection, ensuring the safety and longevity of your electrical systems.

Product Features:

• 1 Pole Configuration: Ideal for single-phase circuits, providing efficient and targeted protection.
• 15 Ampere Rating: Suitable for a wide range of low to medium power applications.
• Curve Type C: Offers fast tripping under short-circuit conditions while allowing temporary overloads without nuisance trips.
• Current Limiting Technology: Limits fault currents to protect downstream equipment from damage.
• Durable Construction: Made from high-quality materials to withstand harsh industrial environments.
• Easy Installation: Designed for quick and secure mounting on DIN rails or panel installations.
• UL Listed & IEC Compliant: Meets international safety and performance standards for global use.

Specifications:

• Voltage Rating: 277V AC, 48V DC
• Interrupting Capacity: 10kA at 277V AC
• Operating Temperature Range: -40°C to +75°C
• Wire Size Compatibility: 18-10 AWG (2-4 wires max per terminal)
• Weight: Approximately 0.2 kg
• Material: Flame-retardant thermoplastic housing

Applications:

• Industrial control panels and machinery
• Commercial electrical systems
• Automation and process control systems
• Lighting and power distribution circuits
• Renewable energy systems (solar, wind)

Benefits:

• Enhanced Safety: Protects equipment and personnel from electrical faults and overloads.
• Reliability: Ensures consistent performance in demanding environments.
• Cost-Effective Protection: Provides superior protection at an affordable price point.
• Long Service Life: Built to last with durable components and corrosion-resistant materials.
• Compliance Assurance: UL Listed and IEC compliant for peace of mind and regulatory adherence.
