DELTA 电子温度控制器 DTB4848LR

Delta DTB4848LR Electronic Temperature Controller is a high-precision industrial-grade temperature control solution designed for demanding commercial and industrial applications. This robust unit offers precise temperature regulation with advanced features to ensure optimal performance in various environments.

Product Features:

• Dual Display: Clear LED indicators for Process Value (PV) and Set Value (SV), allowing easy monitoring of current and target temperatures.
• Wide Input Range: Compatible with AC 100-240V input, making it suitable for global use.
• Multiple Output Options: Supports 4-20mA or 0-10V output signals, providing flexibility for integration with various control systems.
• Advanced Control Algorithms: Equipped with sophisticated PID control for accurate and stable temperature management.
• Relay Outputs: Two relay outputs (OUT1 and OUT2) for controlling auxiliary devices or alarms.
• Alarm Functionality: Built-in alarm output (ALM) for critical temperature threshold notifications.
• Communication Interface: RS-485 serial communication port for remote monitoring and data logging capabilities.
• Durable Construction: Rugged metal casing designed for long-term reliability in harsh industrial environments.
\n
• User-Friendly Interface: Intuitive keypad with SET, arrow keys, and function buttons for easy configuration and operation.

Specifications:

• Model: DTB4848LR
• Voltage Input: AC 100-240V, 50/60 Hz, 5VA
• Temperature Measurement Range: -50°C to 150°C (-58°F to 302°F)
• Accuracy: ±0.5% of full scale
• Display Resolution: 0.1°C / 0.1°F
• Output Signals: 4-20mA or 0-10V
• Relay Outputs: 2 x 3A, 250VAC
• Communication: RS-485 (Modbus RTU protocol)
• Enclosure Rating: IP65 (dust-tight and protected against water jets)
• Dimensions: 96mm x 96mm x 75mm (W x H x D)
• Weight: Approximately 0.5kg

Applications:

• Industrial process control systems
• Heating, ventilation, and air conditioning (HVAC) systems
• Food processing and storage facilities
• Pharmaceutical manufacturing
• Chemical processing plants
• Automotive testing equipment
• Environmental chambers and incubators
• Manufacturing automation systems

Benefits:

• High Precision: Ensures accurate temperature control for consistent product quality.
• Reliability: Built to withstand harsh industrial conditions for long-term performance.
• Flexibility: Multiple input/output options allow integration with various systems and devices.
• Ease of Use: Simple interface and intuitive controls make setup and operation straightforward.
• Cost-Effective: Provides advanced features at an affordable price point for industrial applications.
• Compliance: Meets international safety and quality standards (CE, UL, EAC certified).
• Scalability: Can be easily integrated into larger automation systems for expanded functionality.
