PHOENIX CONTACT 安全继电器 PSR-SCP-24DCMXF34X12X2B 2903257

The Phoenix Contact PSR-SCP-24DC/MXF3/4X1/2X2/B 2903257 Safety Relay is a robust industrial-grade component designed for critical safety applications in commercial and industrial environments. This relay ensures reliable operation in demanding conditions, providing enhanced safety and control for machinery and automation systems.

Product Features:

• Compact Design: The unit features a space-saving design with a yellow housing and green terminal blocks, making it easy to integrate into existing control panels.
• Multiple Output Options: Offers versatile output configurations including 250V AC (6A), 250V AC (3A), 24V DC (5A), and 24V DC (0.1A) for diverse application needs.
• Input Voltage: Operates on a 24V DC input voltage with a tolerance of -15% to +10%, ensuring compatibility with standard industrial power supplies.
• Integrated Diagnostics: Includes LED indicators for power (PWR), error (ERR), and status (I/O2), enabling quick fault detection and system monitoring.
• UL Listed Approval: Certified by UL for industrial use, meeting stringent safety and performance standards.
• Mounting Flexibility: Supports horizontal and vertical mounting options with 10mm module spacing, offering installation versatility.
• Alarm Outputs: Equipped with two alarm outputs for enhanced safety functionality.

Specifications:

• Model Number: PSR-SCP-24DC/MXF3/4X1/2X2/B 2903257
• Input Voltage: 24V DC ±10%
• Output Voltage: 250V AC, 24V DC
• Current Ratings: 6A (250V AC), 3A (250V AC), 5A (24V DC), 0.1A (24V DC)
• Approvals: UL Listed, CE Certified
• Operating Temperature: -25°C to +55°C
• Dimensions: Compact size for easy integration into control systems.

Applications:

This safety relay is ideal for use in a wide range of industrial applications, including:

• Machine safety controls
• Automation systems
• Emergency stop circuits
• Interlock systems
• Process control systems
• Industrial machinery and equipment

Benefits:

• Enhanced Safety: Provides reliable and redundant safety functions to protect personnel and equipment.
• High Reliability: Built to withstand harsh industrial environments, ensuring long-term performance and durability.
• Easy Installation: User-friendly design with clear labeling and mounting options simplifies integration into existing systems.
• Comprehensive Diagnostics: Real-time monitoring through LED indicators reduces downtime and maintenance costs.
• Global Compliance: Meets international safety standards, ensuring compliance with global regulations.
