WEIDMULLER 1 POLE 2 AMP CIRCUIT BREAKER QL-1(13)-DM-KM-2A-LW QL18KM02LW

The WEIDMULLER QL-1(13)-DM-KM-2A-LW (QL18KM02LW) is a compact, single-pole circuit breaker designed for reliable electrical protection in commercial and industrial applications. This robust device features a sleek black housing with a white toggle switch for easy operation, ensuring clear visibility of the ON/OFF status.

Key Features:

• 2 Ampere Rating: Provides precise current control for circuits requiring up to 2 amperes of protection.
• Single-Pole Design: Ideal for use in single-phase systems, offering efficient space utilization in panelboards.
• Tripping Characteristics: Equipped with KM curve tripping characteristics, providing optimal protection against overloads and short circuits.
• Durable Construction: Made from high-quality materials to withstand harsh industrial environments and ensure long-term reliability.
• Mounting Options: Designed for vertical mounting on DIN rails, simplifying installation and maintenance.
• Compliance Standards: Meets international safety standards including EN/IEC 60947-2, UL, and CSA certifications.

Specifications:

• Current Rating: 2A
• Voltage Rating: 240V AC (50/60Hz)
• Interrupting Capacity: 6kA (VC8036 = 5kA)
• Tripping Curve: KM
• Wire Size Compatibility: AWG 2 (35 lbs-in), AWG 4 (28 lbs-in), AWG 18-6 (20 lbs-in)
• Operating Temperature: -25°C to +70°C
• Dimensions: Compact design for easy integration into existing electrical systems.

Applications:

This circuit breaker is suitable for a wide range of applications, including but not limited to:

• Industrial machinery and equipment
• Commercial building electrical systems
• Automation and control panels
• Lighting circuits
• Power distribution units

Benefits:

• Enhanced Safety: Protects electrical circuits from overcurrent conditions, preventing potential damage and hazards.
• Reliability: Built to withstand demanding industrial environments, ensuring consistent performance over time.
• Easy Installation: Designed for quick and straightforward mounting on DIN rails, reducing installation time and effort.
• Cost-Effective: Offers a balance between performance and affordability, making it an ideal choice for various applications.
• Comprehensive Protection: Provides reliable overload and short-circuit protection, safeguarding connected equipment and systems.
