MOOG G400 系列无刷伺服电机 G3L25 G403K002

The MOOG G400 Series G3L25 G403K002 is a high-performance, brushless servo motor designed for demanding industrial automation and motion control applications. This robust motor combines precision engineering with advanced technology to deliver exceptional reliability and efficiency.

Product Features:

• High Torque Density: Provides powerful performance in a compact design, ideal for space-constrained environments.
• Brushless Technology: Eliminates the need for maintenance and ensures long operational life with minimal wear.
• IP65 Rating: Offers superior protection against dust and water ingress, making it suitable for harsh industrial conditions.
• CE Certification: Complies with European safety and quality standards for global use.
• Efficient Cooling System: Integrated heat dissipation features ensure optimal performance even under heavy loads.
• Durable Construction: Built with high-quality materials for enhanced durability and resistance to environmental factors.

Specifications:

• Model: G403K002
• Type: G3L25
• Rated Power (Pn): 1.15 kW
• Maximum Speed (nmax): 5500 min⁻¹
• Rated Torque (Mn): 2.55 Nm
• Inertia (J): 0.62 kgcm²
• Resistance (Rtt): 5.1 Ohm
• Voltage (Ud): 325 V
• Current (Iarms): 3.4 A
• Protection Rating: IP65
• Manufactured In: Germany

Applications:

This versatile motor is ideal for a wide range of industrial applications, including:

• Robotics and Automation Systems
• Material Handling and Packaging Equipment
• CNC Machines and Machining Centers
• Medical Devices and Instrumentation
• Automotive Manufacturing and Assembly Lines
• Textile and Printing Machinery

Benefits:

• Enhanced Precision: Delivers accurate and repeatable motion control for critical applications.
• Energy Efficiency: Optimized design reduces power consumption while maintaining high performance.
• Reliability: Built to withstand demanding industrial environments with minimal downtime.
• Low Maintenance: Brushless design eliminates the need for frequent servicing or replacement of components.
• Scalability: Suitable for integration into existing systems or as part of new installations.
