KEYENCE SAFTEY 轻质传输器 GL-R08H-T

KEYENCE GL-R08H-T Safety Light Curtain Transmitter is a high-performance, compact safety sensor designed for industrial automation and motion control applications. This robust transmitter ensures reliable detection and protection in demanding environments, making it an essential component for safeguarding machinery and operators.

Product Features:

• Compact Design: With a diameter of 25mm (0.98 inches), this lightweight transmitter is easy to install in tight spaces without compromising performance.
• High Detection Precision: Offers a detection height of up to 140mm (185mm with extended settings) and a detection capability of Ø25mm, ensuring accurate object detection.
• Fast Response Time: Achieves response times of 6.6ms (Channel 0) and 6.9ms (Channel AorB), providing rapid detection and reaction for enhanced safety.
• Wide Operating Distance: Supports an operating distance of 0.2m to 15m, making it suitable for various industrial applications.
• Reliable Power Supply: Operates on a 24V DC power supply with a current rating of 43mA, Class 2, ensuring stable and efficient performance.
• Durable Construction: Built to withstand harsh industrial conditions, with a rugged design that resists wear and tear.
• Comprehensive Safety Standards: Meets international safety standards, including CE and UL certifications, ensuring compliance with global regulations.

Specifications:

• Model Number: GL-R08H-T
• Diameter: Ø25mm (0.98 inches)
• Rated Voltage/Current: 24V DC, 43mA
• Type of Power Supply: Class 2
• Response Time: 6.6ms / 6.9ms
• Detection Height: 140mm (185mm with extended settings)
• Detection Capability: Ø25mm (default setting)
• OSSD Rating: PNP/NPN max 500mA
• Operating Distance: 0.2m - 15m
• EAA: ±2.5° (3m or more)

Applications:

• Machinery Protection: Ideal for safeguarding moving parts in industrial machinery, preventing accidents and ensuring operator safety.
• Automated Assembly Lines: Enhances the safety and efficiency of automated assembly processes by detecting objects and stopping machinery when necessary.
• Robotics Integration: Seamlessly integrates with robotic systems to provide real-time object detection and prevent collisions.
• Conveyor Systems: Ensures safe operation of conveyor systems by detecting objects and stopping the system if an obstruction is detected.
• Workplace Safety: Provides an additional layer of safety in workspaces by detecting unauthorized access and triggering alarms or shutdowns.

Benefits:

• Enhanced Safety: Provides reliable object detection and protection, reducing the risk of accidents and injuries in industrial environments.
• Improved Efficiency: Fast response times and precise detection capabilities ensure smooth and efficient operation of machinery and automated systems.
• Cost-Effective: Compact design and durable construction reduce installation and maintenance costs, offering long-term value.
• Compliance: Meets international safety standards, ensuring compliance with global regulations and reducing liability risks.
• Versatility: Suitable for a wide range of applications, from small-scale operations to large industrial setups.
