SCHNEIDER 反向起动器 LF4MP05EU

Schneider Electric LF4MP05EU Reverse Starter is a robust industrial-grade device designed for reliable motor control in demanding applications. This reverse starter enables precise directional control of motors, making it ideal for use in conveyor systems, pumps, and other machinery requiring bidirectional operation.

Key Features:

• Dual Direction Control: Provides forward and reverse motor operation with a single unit, eliminating the need for separate starters.
• Compact Design: IP54-rated enclosure ensures protection against dust and water ingress, suitable for both indoor and outdoor installations.
• Integrated Safety Mechanisms: Includes auxiliary power terminals and fault indicators for enhanced monitoring and diagnostics.
• Wide Power Range: Supports standard power ratings from 0.06 kW to 5.5 kW (200/230VAC to 400/415VAC), accommodating various motor sizes.
• UL Listed: Certified for safety compliance, meeting stringent industry standards for electrical equipment.
• Easy Installation: Pre-wired components and clear labeling simplify setup and maintenance.

Specifications:

• Model: LF4MP05EU
• Voltage Rating: 200-415V AC
• Frequency: 50/60Hz
• Enclosure Rating: IP54
• Maximum Horsepower Ratings: Up to 10 HP (3-phase)
• Short Circuit Current Rating: 80,000 A rms at 480V
• Manufactured Date: July 19, 2017
• Country of Origin: Made in France

Applications:

• Conveyor Systems
• Pump Controls
• Material Handling Equipment
• Automated Production Lines
• Industrial Machinery

Benefits:

• Enhanced Efficiency: Optimizes motor performance by providing precise directional control.
• Reliability: Built with high-quality components for long-lasting operation in harsh environments.
• Cost-Effective: Combines multiple functions into one unit, reducing installation and maintenance costs.
• Compliance: Meets international safety and performance standards for peace of mind.
• Easy Maintenance: Accessible internal components and clear labeling facilitate troubleshooting and servicing.
