O. THOMPSON CO. Infrared Detector Rev C and Emitter Board Rev C M00151 & M00154 M297

O. THOMPSON CO. Infrared Detector and Emitter Board Set (REV C)

Introducing the O. Thompson Corp. Infrared Detector and Emitter Board Set, a high-performance solution for industrial and commercial applications requiring precise infrared sensing and emission capabilities. This set includes two boards: the M00154 Emitter Board and the M00151 Detector Board, both designed with advanced circuitry for reliable operation in demanding environments.

Product Features:

• High Precision Infrared Technology: Utilizes state-of-the-art infrared sensors and emitters for accurate detection and transmission of infrared signals.
• Durable Construction: Built with robust materials to withstand harsh industrial conditions, ensuring long-term reliability and performance.
• Compact Design: Optimized for easy integration into existing systems, with a slim profile that saves space without compromising functionality.
• Advanced Circuitry: Incorporates sophisticated electronic components for enhanced signal processing and reduced interference.
• Easy Connectivity: Equipped with multiple connection points and a color-coded ribbon cable for straightforward installation and maintenance.
• Comprehensive Labeling: Clearly marked with model numbers and revision details for quick identification and reference.

Specifications:

• Model Numbers: M00154 (Emitter Board), M00151 (Detector Board)
• Revision: REV C
• Material: High-quality green PCB with durable solder joints
• Dimensions: Approximately 150mm x 75mm (Emitter Board), 150mm x 75mm (Detector Board)
• Operating Temperature: -20°C to +70°C
• Connectivity: Multiple pin connectors and a 10-pin ribbon cable

Applications:

• Industrial Automation: Ideal for use in automated systems requiring precise infrared sensing for object detection, positioning, and alignment.
• Security Systems: Enhances security applications by providing reliable infrared detection for intrusion alarms and surveillance systems.
• Medical Devices: Suitable for medical equipment that utilizes infrared technology for non-invasive monitoring and diagnostic purposes.
• Consumer Electronics: Can be integrated into various consumer electronics for features such as touchless controls and proximity sensing.
• Research and Development: Valuable for R&D projects involving infrared technology, offering a versatile platform for experimentation and prototyping.

Benefits:

• Enhanced Accuracy: Delivers precise infrared detection and emission, improving the overall performance of your systems.
• Reliability: Designed for durability and consistent performance, even in challenging environments.
• Cost-Effective: Offers a robust solution at a competitive price point, making it an economical choice for various applications.
• Ease of Integration: Simplifies installation and maintenance with clear labeling and user-friendly connectivity options.
• Future-Proof: Built with the latest technology to ensure compatibility with current and future systems.
