ALLEN BRADLEY KINETIX 5700 290A LINE FILTER 2198-DB290-FA

The Allen Bradley Kinetix 5700 290A Line Filter (Part Number 2198-DB290-F/A) is a robust industrial component designed for use in demanding electrical environments. This high-performance line filter is engineered to protect sensitive equipment from voltage spikes, harmonics, and electromagnetic interference, ensuring reliable operation of AC drives and other critical systems.

Key Features:

• Three-Phase Design: Specifically configured for three-phase AC drive applications, providing balanced filtering across all phases.
• 290 Amp Capacity: Handles substantial current loads up to 290 amps at 480VAC, making it suitable for heavy-duty industrial machinery.
• Temperature Rating: Operates efficiently at temperatures up to 60°C, ensuring durability in harsh industrial conditions.
• Permanent Earthing Mandatory: Includes clear safety warnings and instructions for proper installation and grounding to prevent electrical hazards.
• Durable Construction: Encased in a sturdy metal housing with secure terminal connections for long-lasting performance.
• Compliance Certifications: Meets UL, CSA, and CE standards, guaranteeing safety and reliability in global markets.

Specifications:

• Part Number: 2198-DB290-F/A
• Current Rating: 290 Amps @ 50°C
• Voltage Rating: 480VAC
• Phase Configuration: Three Phase
• Material: Metal Housing with Copper Terminals
• Weight: Approximately 10 kg (subject to variation)
• Dimensions: 250mm x 150mm x 100mm (L x W x H)
• Manufactured By: Rockwell Automation, Product of the United Kingdom

Applications:

• Industrial automation systems
• Motor control centers
• Variable frequency drives (VFDs)
• Heavy machinery and manufacturing equipment
• Power distribution networks

Benefits:

• Enhanced Equipment Protection: Safeguards sensitive electronics from voltage fluctuations and harmonic distortion.
• Improved System Efficiency: Reduces energy losses and extends the lifespan of connected equipment.
• Regulatory Compliance: Meets international safety and performance standards for industrial use.
• Reliable Performance: Designed for continuous operation in demanding industrial environments.
• Easy Installation: Pre-wired terminals and clear labeling simplify integration into existing systems.
