Product Description
The Hauch & Bach PGM 86.1 Profibus Gateway Module is a robust industrial communication solution designed for seamless integration into existing Profibus V1 DP networks. This compact, metallic module features a durable aluminum housing with precise engineering for reliable performance in demanding environments.
Key Features:
- Profibus V1 DP-Network compatibility for efficient data exchange
- Integrated DIP switch for easy address configuration (0-63)
- RS-485 network interface with DB9 connector for versatile connectivity
- Power and communication status indicators for quick system monitoring
- CE certified for compliance with European safety standards
- Durable aluminum construction for long-term reliability
Specifications:
- Part Number: 86.101.5.v.1.2x
- Operating Temperature: -25°C to +70°C
- Supply Voltage: 24V DC
- Communication Rate: Up to 12 Mbps
- Dimensions: 100mm x 25mm x 60mm (LxWxH)
- Weight: Approximately 250g
Applications:
This gateway module is ideal for industrial automation systems requiring integration of non-Profibus devices into a Profibus network. It's commonly used in manufacturing plants, process control systems, and automated production lines where reliable data exchange between different protocols is essential.
Benefits:
- Enhanced interoperability between various industrial devices
- Improved network efficiency through optimized data transfer
- Easy installation and configuration with clear labeling
- Long-term reliability with industrial-grade components
- Cost-effective solution for upgrading existing Profibus systems
Product Gallery
