SIEMENS 3 POLE 16 AMP CIRCUIT BREAKER MCB C16 AUX. 5ST3010-0HG 5SY6316-7

The Siemens 3 Pole 16 Amp Circuit Breaker MCB C16 Aux. 5ST3010-0HG is a high-performance electrical protection device designed for commercial and industrial applications. This robust circuit breaker ensures reliable operation in demanding environments, providing essential overcurrent and short-circuit protection for electrical systems.

Product Features:

• Three-pole configuration for comprehensive protection in three-phase systems
• Rated current of 16 Amps with C16 tripping characteristics for precise overload detection
• Integrated auxiliary switch (model 5ST3010-0HG) for signaling and control purposes
• Compact design with DIN rail mounting capability for easy installation
• Durable white thermoplastic housing resistant to environmental factors
• Clear ON/OFF indicator for quick status verification
• Compliant with international standards including IEC/EN 62098 and UL 489

Specifications:

• Model Number: 5SY6316-7
• Auxiliary Switch Model: 5ST3010-0HG
• Number of Poles: 3
• Rated Current: 16A
• Tripping Characteristics: C16
• Voltage Rating: ~400V
• Interrupting Capacity: 6kA
• Mounting Type: DIN Rail
• Material: Thermoplastic Housing
• Weight: Approximately 0.5kg

Applications:

• Industrial control panels and automation systems
• Commercial building electrical distribution boards
• Manufacturing equipment protection
• Renewable energy systems (solar, wind)
• Building management systems
• Heavy-duty machinery protection

Benefits:

• Enhanced safety through reliable overcurrent protection
• Improved system reliability with precise tripping characteristics
• Space-saving design for efficient panel utilization
• Easy integration with existing Siemens electrical systems
• Long-lasting performance with durable construction
• Comprehensive documentation and technical support available
• Cost-effective solution for protecting critical electrical infrastructure
