富士电气 3 POLE 30 安培地球泄漏断路器 SG53B

The Fuji Electric SG53B 3-Pole 30 Amp Earth Leakage Breaker is a robust and reliable electrical safety device designed for commercial and industrial applications. This high-performance circuit breaker provides essential protection against earth leakage faults, ensuring the safety of both personnel and equipment.

Product Features:

• 3-Pole Configuration: Offers comprehensive protection for three-phase electrical systems.
• 30 Amp Rating: Suitable for a wide range of industrial and commercial power requirements.
• Earth Leakage Protection: Detects and interrupts earth leakage currents to prevent electric shocks and potential fires.
• Indicating Button: Clearly shows the status of the breaker with an illuminated indicator light.
• Test Button: Allows for easy verification of the breaker's functionality before operating connected appliances.
• Durable Construction: Built with high-quality materials to withstand harsh industrial environments.
• Compact Design: Space-saving form factor for easy installation in tight electrical panels.

Specifications:

• Voltage Rating: 200-550V (maximum 605V)
• Frequency: 50/60Hz
• Sensitivity: 30mA
• Interrupting Capacity: 10kA at 200V, 2.5kA at 550V
• Tripping Time: Maximum 0.1 seconds
• Ambient Temperature: Up to 40°C
• Material: High-grade thermoplastic housing for durability and safety

Applications:

• Industrial machinery and equipment
• Commercial buildings and facilities
• Manufacturing plants and production lines
• Power distribution systems
• Electrical installations requiring earth leakage protection

Benefits:

• Enhanced Safety: Protects against electric shocks and potential fire hazards caused by earth leakage faults.
• Reliability: Ensures consistent performance and long-lasting operation in demanding environments.
• Easy Maintenance: Simple-to-use test button and clear status indicators for quick troubleshooting.
• Compliance: Meets international safety standards for electrical installations.
• Cost-Effective: Provides superior protection at an affordable price point for industrial and commercial use.
