NIDEC UNIDRIVE M300 M300-024 00041 A

NIDEC UNIDRIVE M300-024 00041 A is a high-performance industrial variable frequency drive (VFD) designed for precise motor control in demanding applications. This robust unit combines advanced control techniques with reliable engineering to deliver exceptional efficiency and versatility.

Product Features:

• Digital Display Panel: Intuitive interface with clear LED readouts for voltage, current, frequency, speed, and percentage values.
• Control Buttons: Dedicated buttons for parameter adjustment, mode selection, and emergency stop functions.
• Green Label Interface: Clearly marked control parameters including minimum/maximum speed, acceleration/deceleration rates, motor ratings, and drive configuration options.
• Industrial Grade Construction: Durable white casing with ventilation slots for optimal heat dissipation during continuous operation.
• Terminal Block Connections: Secure screw terminals for easy and reliable power and signal connections.
• Comprehensive Safety Features: Built-in safety warnings and certifications including CE, UL, and EAC compliance.

Specifications:

• Model Number: M300-024 00041 A
• Power Rating: 1.5kW (1842-1840)
• Input Voltage: 380-480V AC, 3-phase, 50-60Hz
• Output Voltage: 0-480V AC, 3-phase, 0-550Hz
• Current Ratings: 6.2A (input), 4.1A (output)
• Protection Rating: IP38
• Designed In: UK
• Made In: China
• Certifications: EAC, CE, UL Listed

Applications:

• Industrial automation systems requiring precise motor speed control
• Conveyor belt systems and material handling equipment
• Pump and fan control applications
• Textile machinery and manufacturing processes
• Energy-efficient motor control solutions
• Process control systems in various industrial sectors

Benefits:

• Enhanced Efficiency: Optimized energy consumption through precise motor speed regulation.
• Improved Productivity: Consistent performance and reduced downtime due to reliable operation.
• Extended Equipment Life: Reduced mechanical stress on motors and connected equipment through smooth acceleration and deceleration.
• Cost Savings: Lower energy costs and reduced maintenance requirements over the product lifecycle.
• Easy Integration: Standardized interfaces and comprehensive documentation for seamless system integration.
• Global Compliance: Meets international safety and quality standards for worldwide deployment.
