Product Description
The Allen-Bradley 100-C23E*10 is a high-performance 24V DC electric contact block designed for demanding industrial applications. This robust component features a compact, durable design with a gray thermoplastic housing that ensures long-lasting reliability in harsh environments.
- Key Features:
- Rated for 24V DC operation, ensuring compatibility with low-voltage control circuits.
- Three-pole configuration with clearly labeled terminal connections (L1, L2, L3 and T1, T2, T3) for easy installation and maintenance.
- Integrated auxiliary contacts for enhanced functionality and monitoring capabilities.
- UL and CE certified, meeting international safety and quality standards.
- Compact dimensions (approx. 50mm x 30mm x 60mm) for space-efficient integration into control panels.
- Durable construction with a thermoplastic housing resistant to dust, moisture, and chemical exposure.
Specifications:
- Voltage Rating: 24V DC
- Current Rating: 32A (AC-3), 20A (AC-12)
- Insulation Resistance: 100MΩ minimum
- Dielectric Strength: 2kV AC for 1 minute
- Operating Temperature Range: -25°C to +55°C
- Weight: Approximately 250g
Applications:
This versatile electric contact block is ideal for use in various industrial automation systems, including:
- Motor control circuits
- Machine tool operations
- Conveyor systems
- Process control equipment
- Robotics and automated assembly lines
Benefits:
- Enhanced safety through UL and CE certifications
- Improved system reliability with durable construction
- Easy installation and maintenance due to clear labeling and accessible terminals
- Space-saving design for efficient panel utilization
- Cost-effective solution for industrial control applications
