西门子定位开关超长垫 3SE2 200-1C

Siemens 3SE2 200-1C Position Switch is a high-quality industrial limit switch designed for precise and reliable operation in demanding environments. This robust switch features an overtravel plunger mechanism, ensuring accurate position detection and control in various applications.

Product Features:

• Overtravel Plunger Design: Provides enhanced durability and consistent performance even under heavy-duty conditions.
• 1NO+1NC Contacts: Offers versatile connectivity options for both normally open and normally closed circuits.
• Compact and Durable Housing: Constructed from high-grade materials to withstand harsh industrial environments.
• IP67 Rating: Ensures protection against dust ingress and temporary water immersion, making it suitable for outdoor and wet locations.
• CE and UL Certified: Meets international safety and quality standards for global use.
• Easy Installation: Designed with convenient mounting options for seamless integration into existing systems.

Specifications:

• Model Number: 3SE2 200-1C
• Contact Configuration: 1NO + 1NC (snap action)
• Voltage Rating: AC 500V / DC 300V
• Current Rating: 6A at 250V AC
• Insulation Resistance: 100 MΩ minimum
• Dielectric Strength: 6 kV AC for 1 minute
• Protection Rating: IP67
• Operating Temperature Range: -25°C to +85°C
• Dimensions: Compact size for easy installation in tight spaces
• Weight: Lightweight design for minimal system impact

Applications:

• Machinery Control: Ideal for use in automated manufacturing systems, conveyor belts, and robotic applications.
• Industrial Automation: Perfect for integrating into PLC-controlled systems for precise motion control.
• Material Handling: Suitable for cranes, hoists, and other material handling equipment requiring reliable position sensing.
• Building Automation: Can be used in HVAC systems, elevators, and other building automation applications.
• Heavy Equipment: Designed to withstand the rigors of construction, mining, and agricultural machinery.

Benefits:

• Reliability: Built to deliver consistent performance in even the most challenging industrial environments.
• Longevity: High-quality components ensure extended service life and reduced maintenance costs.
• Accuracy: Overtravel plunger design provides precise position detection for optimal system performance.
• Cost-Effective: Combines superior quality with competitive pricing for excellent value.
• Global Compatibility: Meets international standards for use in diverse markets worldwide.
