TOLOMATIC SERVOWELD FANUC ACTUATOR SERVO ACTUATOR 6 英寸 STROKE GSWA04-MV23 27500113

TOLOMATIC SERVOWELD FANUC ACTUATOR (Model: GSWA04-MV23, Serial #: J317964-1) is a high-performance linear servo actuator designed for precision industrial automation applications. This robust and reliable actuator delivers exceptional accuracy and repeatability, making it ideal for demanding manufacturing processes.

Key Features:

• 6-Inch Stroke Length: Provides ample linear motion for a wide range of applications.
• Patented Roller Screw Technology: Ensures smooth operation, high efficiency, and long service life.
• Fanuc Feedback System: Offers precise position control and real-time monitoring for enhanced performance.
• High Force Output: Continuous force of 3.7 kN (825 lbs) and peak force of 11.1 kN (2500 lbs) for heavy-duty tasks.
• Compact Design: Space-saving form factor allows easy integration into existing systems.
• Durable Construction: Built to withstand harsh industrial environments with a rugged metal housing.
• CE Certified: Meets European safety and quality standards for global use.

Specifications:

• Maximum Stroke: 152.4 mm (6.00 in)
• Displacement: 10 mm/rev
• Ratio: 0.39 in/rev
• Continuous Force: 3.7 kN (825 lbs)
• Peak Force: 11.1 kN (2500 lbs)
• Maximum Terminal Voltage: 325 Vdc
• Maximum Current: 29.1 A RMS
• Maximum Speed: 583 mm/sec (23.0 in/sec)
• Feedback System: Fanuc/A64
• Product of USA

Applications:

• Automated assembly lines
• Welding and fabrication equipment
• Material handling and positioning systems
• Robotic automation
• Testing and measurement devices
• Custom machinery and equipment

Benefits:

• Enhanced productivity and efficiency in industrial processes
• Improved accuracy and repeatability for consistent results
• Reduced maintenance costs due to durable construction and reliable performance
• Easy integration with existing Fanuc-based systems
• Compliance with international safety and quality standards
• Cost-effective solution for high-force linear motion requirements
