IFM 电子控制器 500 压力传感器 PN5001

The IFM PN5001 Pressure Sensor is a high-precision industrial-grade device designed for reliable pressure measurement in demanding environments. Manufactured by IFM electronic, a trusted name in industrial automation, this sensor combines durability with advanced digital technology.

Key Features:

• Digital display with multiple unit options (bar, MPa, PSI)
• Wide pressure range: 0...250 bar, 0...25.0 MPa, 0...3625 PSI
• Maximum pressure rating of 400 bar, 40 MPa, and 5800 PSI
• IP67 protection rating for dustproof and waterproof operation
• CE and UL listed for compliance with international safety standards
• Robust stainless steel construction for long-lasting performance
• Compact design with threaded connection for easy installation
• Two-button interface for simple configuration and calibration

Specifications:

• Model: PN5001
• Pressure Range: 0...250 bar, 0...25.0 MPa, 0...3625 PSI
• Maximum Pressure: 400 bar, 40 MPa, 5800 PSI
• Protection Rating: IP67
• Connection: Threaded (NPT or metric)
• Display: Red LED digital readout
• Power Supply: 10-30 VDC
• Operating Temperature: -40°C to +85°C
• Weight: Approximately 250g

Applications:

This versatile pressure sensor is ideal for a wide range of industrial applications, including:

• Hydraulic and pneumatic systems
• Fluid power control
• Process monitoring and control
• Machine tool applications
• Automotive testing and diagnostics
• Oil and gas industry
• Water treatment and distribution systems
• Medical equipment

Benefits:

• High accuracy and repeatability for precise measurements
• Long-term stability and reliability for continuous operation
• Easy-to-read digital display for quick pressure readings
• Simple setup and configuration for user-friendly operation
• Comprehensive protection against harsh environmental conditions
• Compatible with various industrial systems and protocols
• Cost-effective solution for accurate pressure monitoring
