AST BR SERIES AC MOTOR BRR 75-1A-1000

The AST BR Series AC Motor, model BRR 75-1A-1000, is a high-performance industrial motor designed for demanding automation and motion control applications. This brushless permanent magnet (PM) motor combines precision engineering with robust construction to deliver exceptional reliability and efficiency in commercial and industrial environments.

Key Features:

• High Torque Density: Provides 1.3 Nm continuous torque and up to 3.9 Nm peak torque for powerful performance in various applications.
• Brushless Design: Eliminates wear-prone brushes, reducing maintenance requirements and extending operational life.
• Advanced Cooling System: Integrated heat dissipation fins ensure optimal thermal management even under heavy loads.
• Robust Connectors: Equipped with durable M12 connectors for secure and reliable electrical connections.
• IP65 Rating: Offers excellent protection against dust and water ingress, suitable for harsh industrial environments.
• Resolver Feedback: Ensures precise position and speed control for accurate motion applications.
• Compact Design: Optimized footprint for easy integration into existing systems and machinery.

Specifications:

• Type: BRR 75-1A-1000
• Voltage: 220V
• Continuous Current: 2.4 Amps
• Peak Current: 7.2 Amps
• Continuous Torque: 1.3 Nm
• Peak Torque: 3.9 Nm
• Poles: 6 poles
• Protection Rating: IP65
• Feedback: Resolver
• Weight: Approximately 7.5 kg

Applications:

• Automated Assembly Lines
• Robotics Systems
• CNC Machines
• Material Handling Equipment
• Printing and Packaging Machinery
• Medical Device Automation
• Test and Measurement Equipment

Benefits:

• Enhanced productivity through precise and reliable motion control
• Reduced downtime and maintenance costs due to durable construction
• Improved energy efficiency compared to traditional motor technologies
• Flexible integration options for various industrial automation systems
• Compliance with international safety and quality standards (CE, UL)
• Long-term cost savings through extended operational life and reduced replacement frequency
