PHOENIX CONTACT PROGRAMABLE CURRENT TRANSDUCER MCR-S-1050-UI-SW-DCI 2814663

Phoenix Contact MCR-S-10/50-UI-SW-DCI Programmable Current Transducer is a high-precision industrial component designed for accurate current measurement and signal processing in demanding automation environments. This robust device features a compact, green housing with DIN rail mounting capability, ensuring easy integration into existing control systems.

Key Features:

• Programmable current transducer for precise measurement of AC and DC currents
• Wide input range: 10-50 A AC/DC
• Signal output options: 4-20 mA, 0-10 V, or 0-20 mA
• Integrated relay output for switching applications
• LED indicators for power, zero adjustment, span calibration, and time settings
• Comprehensive terminal block for easy wiring and connectivity
• Compliant with hazardous location standards (Class I, Div. 2; Class II, Div. 1)
• Durable construction suitable for industrial environments

Specifications:

• Input Current Range: 10-50 A AC/DC
• Output Signal: 4-20 mA, 0-10 V, or 0-20 mA
• Power Supply: +24 V DC
• Relay Output: 50 mA, 30 V AC / 36 V DC
• Operating Temperature: -25°C to +71°C
• Enclosure Rating: IP20
• Mounting: DIN rail (EN 50022)
• Dimensions: 45.5 mm x 90 mm x 22.5 mm

Applications:

• Industrial automation systems
• Motion control applications
• Process monitoring and control
• Energy management systems
• Machine tool control
• Building automation systems
• Renewable energy installations

Benefits:

• High accuracy and reliability for critical current measurement
• Flexible configuration options for various industrial applications
• Easy-to-use interface with clear LED indicators for quick setup and troubleshooting
• Robust design for long-term performance in harsh industrial environments
• Compliance with international safety standards for use in hazardous locations
• Compact size for space-efficient installation in control panels
• Cost-effective solution for precise current measurement and signal conversion
